Non-asbestos Sheet Asseals Non-asbestos sheet is made from Kevlar fiber,natural rubber,filling material and dye ,comprssed and calendered under high temperature into a sheet form.it eliminates asbestos-rubber sheet essentially and thoroughly. Oil-Resisting Non-asbestos Sheet Asseals oil-resisting non-asbestos sheet is made from Kevlar fiber,synthetic rubber,filling material and dey,compressed and calendered underhigh temperature and pressure into a sheet form,it eliminates asbestos-rubber sheet essentially and thoroughly.
Main Properties£º
Item |
Non-asbestos Sheet |
Oil-Resisting Non-asbestos Sheet |
GS4100 |
GS4102 |
GS4104 |
GS4110 |
GS4112 |
GS4114 |
Density g/cm³ |
1.7-1.9 |
1.7-1.9 |
1.7-1.9 |
1.7-1.9 |
1.7-1.9 |
1.7-1.9 |
Tensile strength Mpa |
6 |
9 |
12.5 |
8 |
11 |
12 |
Comperssibility¡Ý£¥ |
12¡À5 |
12¡À5 |
12¡À5 |
12¡À5 |
12¡À5 |
12¡À5 |
Recovery¡Ý£¥ |
40 |
45 |
45 |
45 |
50 |
50 |
Stress relaxation rate¡Ü£¥ |
45 |
45 |
45 |
45 |
45 |
45 |
Tmax:¡æ |
200 |
300 |
400 |
200 |
300 |
350 |
Pmax:Mpa |
1.5 |
3.0 |
5.0 |
2.0 |
3.0 |
3.5 |
Resistance to media |
Water,steam,fuel,gases,and many other media |
Oil fuel,gases,salt solutions and many other media. |
Normal Size |
Width£º1500mm , 1350mm ; Length£º1000mm , 1350 ,2000mm;Thickness£º0.5-5mm |
Normal colour |
|
Availabel with tin steel,copper,SS304etc.wire mesh insertion--GS 41**I Also available with anti-stick or graphite coating--GS 41**G Cut gasket styleGS 41**,Dimensions according to drawings or specifications and standards. |
