Expanded Graphite sheet reinforced smooth SS304
Expanded Graphite sheet reinforced smooth SS304
Item: A.S.SEALS.4002
Description:
Send Inquiry Now! Live Chat Now!

Specification:
Asseals Pure Expanded graphite sheets are made from high purity flexible expanded graphite without fibers,binders or other additives. it offers excellent sealing capabilities such as thermal stability,shlf-lubrication,corrosion resistance,without being brittle and aging etc.,under extreme conditions with a longer life and less maintenance.Asseals graphite sheets are available as homogeneous,reinforced by metal mesh,foil or tanged metal.Allsheets can be easily cut using conventional steel rule dies,utility knives or other simple gasket cutting equipment. GS 4000(R) Expanded Graphite Sheet/Roll GS 4002 Graphite Sheet Reinforced with smooth metal GS 4004 Graphite sheet reinforced with Tan ged metal GS 4006 Graphite sheet reinforced with metal mesh.

Style Insert material Compressibility Recovery Pressure Density With Thickness Application
4000 None 30£¥ 15£¥ 50bar 0.7g/cm³
1.0g/cm³
1000mm
1500mm
0.2-1.0
0.5-3.2
PH:0-14
Made for various gaskets,used in petrochemical,mining.
vessels,bolibers,piping and duct,pumps and valves.flanges etc.
Suitable for stema,mineral oils,heat transfer oils,hydraulic oil,fuel,water,seawater,freshwter etc.
4002 SS304,316etc,
foil(T:0.05mm)
15-35£¥
¡Ý20£¥
200bar 1.0g/cm³ 1000mm
1500mm
0.8-3.2
4004 CS(T:0.05mm) 15-35£¥ ¡Ý20£¥ 300bar 1.0g/cm³ 1000mm
1500mm
1.0-3.2
4006 CS 15-35£¥ ¡Ý20£¥ 200bar 1.0-1.1g/cm³ 1000mm
1500mm
1.0-3.2

Graphite Properties

Item Tolerance of density C¡Ý£¥ Tensile strength Sulphur content Chlorine content Stress relaxation rate lgnition loss Temperature
Industrial ¡À0.06 98 4 1000 50 10 2.0 -240-450¡æ
Nuclear ¡À0.05 99.5 5 700 35 10 0.5
