Barided Carbonized fiber packing impregnated with PTFE
Barided Carbonized fiber packing impregnated with PTFE
Item: A.S.SEALS.2100
Description:
Send Inquiry Now! Live Chat Now!

Specification:

Carbonized Fiber Asseals 2100 Carbonized Fiber Packing Braided from shrink-proof oxdized polyacrylonitrile fiber impregnated with PTFE dispersion containing graphite particles,silicon-oil-free,Compared to traditional carbon fiber packing,it is not brittle,can suited for high peripheral speeds.It has high strength and good thermal conductivity.PTFE and graphite mades the packing have excellent self-lubrication,so thes packing does not damage shafts and has long life. Asseals2100I Carbonized Fiber Packing Reinforced with Nickel wire The wire reinforcement provides incerased mechanical strength,usually for static. Application:Used in weak acds and alkalis or media containing few grains of solid particles,both dynamic and static,mainly used for centrifugal pumps,plunger pumps,mixers and valves.

Service Limits

T 280¡æ
PH 2-12
V 25m/s
Pressure Rotating 20bar
Reciprocating 100bar
Valve 200bar
D(g/cm³)

1.1-1.3

Forms of supply£º
2-5Kg/roll
Packing Ring£ºR2000(I)
