Asbestos rubber sheet

Item: A.S.SEALS.AIFLON30

Description:

Specification:

CONSTRUCTION:

Asseals CAF are made from selected asbestos fibre, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields.

PROPERTIES & APPLICATION:

Item	Style
Item	3030	3035	3040	3045
Tensile strength¡ÝMpa	9	12	15	19
Aging coefficient	0.9	0.9	0.9	0.9
Loss on ignition ¡Ü%	30	30	28	28
Compressibility ¡Ý%	12¡À5	12¡À5	12¡À5	12¡À5
Recovery ¡Ý%	40	40	45	45
Density g/cm³	1.6~2.0
Tmax: ¡æ	300	350	400	450
Pmax: Mpa	3.0	4.0	5.0	6.0
Resistance to media	Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure.

Lower Grade 3015, 3025 on request

Available color: Purple, red, black, grey etc.

Available with tin steel, copper, SS304 etc. wire mesh insertion (30**I)

Also available with anti-stick£??30**S£©or graphite coating (30**G)

FORMS OF SUPPLY:

Sheets:

2000¡Á1500mm; 2000¡Á4000mm;1500¡Á1500mm;

1500¡Á1000mm;1270¡Á1270mm; 3810¡Á1270mm

Thickness: 0.5~6mm

Cut gaskets

G3015~G3045

Dimensions according to drawings or and standards
